Pneumatic Triple-Offset Hard-Sealing Butterfly Valve

The Pneumatic Triple-Offset Hard-Sealing Butterfly Valve is a high-performance industrial valve designed for reliable shut-off and flow control in demanding applications. It combines a triple-offset disc design with a pneumatic actuator, providing excellent sealing performance, low operating torque, and long service life.

The triple-offset design eliminates rubbing between the sealing surfaces during normal operation. As the valve opens and closes, the disc moves away from the seat, significantly reducing friction and wear. When the valve reaches the fully closed position, the disc and metal seat form a tight mechanical seal, providing reliable shut-off performance.

The valve adopts a metal-to-metal hard sealing structure, making it suitable for high-temperature, high-pressure, and harsh operating conditions where conventional soft-seated butterfly valves may not be appropriate.

The pneumatic actuator provides fast and reliable valve operation and can be configured for automatic or remote control. With suitable accessories such as a positioner, solenoid valve, limit switch, and air filter regulator, the valve can be easily integrated into PLC, DCS, and other industrial automation systems.

Key Features

• Triple-offset butterfly valve design
• Metal-to-metal hard sealing
• Excellent shut-off performance
• Low friction and low operating torque
• Reduced seat wear and extended service life
• Suitable for high-temperature and high-pressure applications
• Pneumatic actuator for fast and reliable operation
• Suitable for automatic and remote control
• Excellent resistance to thermal deformation and wear
• Compact and lightweight construction
• Easy integration with PLC and DCS control systems
• Various materials, sizes, and pressure ratings available

Working Principle

The triple-offset design consists of three geometric offsets between the valve stem, the centerline of the disc, and the sealing surface.

During opening and closing, the disc moves away from the sealing seat, minimizing friction and mechanical wear. Near the fully closed position, the disc engages the metal seat to create a tight and reliable seal.

The pneumatic actuator uses compressed air to rotate the valve shaft and disc. Depending on the actuator configuration, the valve can be operated as double-acting or spring-return for different process and fail-safe requirements.

Applications

The Pneumatic Triple-Offset Hard-Sealing Butterfly Valve is widely used in:

• Oil & Gas
• Petrochemical Industries
• Chemical Processing
• Power Generation
• Steam Systems
• High-Temperature Fluid Systems
• Refineries
• Marine and Offshore Applications
• Metallurgy
• Industrial Process Pipelines

It is particularly suitable for applications involving high temperature, high pressure, steam, gas, hydrocarbons, and other demanding process media.

Product Advantages

The triple-offset metal-seated design provides reliable sealing performance while minimizing friction between the disc and seat. This results in reduced wear, lower operating torque, and extended valve service life.

Compared with conventional butterfly valves, the triple-offset configuration is well suited to severe-service applications where high temperature, pressure fluctuations, and long-term reliability are critical.

The valve can be customized according to specific operating conditions, including valve size, pressure class, body material, disc material, seat material, actuator configuration, connection type, control accessories, and fail-safe function.

Technical Specifications

The Pneumatic Triple-Offset Hard-Sealing Butterfly Valve provides a reliable combination of tight shut-off, low operating torque, high-temperature resistance, wear resistance, and long service life, making it an ideal solution for severe industrial process applications.
